• Antenna, fixed mast
• Door handles, Black
• Grille, base, molded in color, Black
• Wheels, 19.5" x 6.75", steel, Black painted, 8-holes, hub piloted (STD)
• Front fender extension, painted body color
• Lamps, cargo area, cab mounted with switch on center switch bank
• Lamps, Smoked Amber roof marker
• Headlamps, halogen projector-beam
• Bumper, front, Black
• Lamps, rear, stop/turn/backup (1-piece assembly) with license plate light
• Grille guard screen, insect protection (mounted behind grille)
• Wheels, 19.5" x 6.75", steel, Black painted, 8-holes, hub piloted (STD)
• Provision for cab roof-mounted lamp/beacon provides an overhead console mounted switch and electrical wiring tucked beneath the headliner for a body upfitter to connect a body-mounted warning or emergency lamp
• Tires, front 225/70R19.5G traction blackwall Goodyear Max Axle Load: 7,940 lb.
• Auxiliary harness, 3' for headlamps and turn signals
• Wheel, 19.5" x 6.75", spare, steel, Black, 8-holes temporary mounted on frame, hub piloted
• Sterling Gray Metallic
• Paint Scheme, Style 1
• Tire, Spare 225/70R19.5G traction blackwall Goodyear Includes (V33) Rim Wrench and handle only tool kit.)
• Mirrors, outside, black, heated power-adjustable, high-visibility vertical camper-style, and lower convex spotter glass, manual-folding. Convex glass is not heated and not power adjustable. 102", Wide Load
• Glass, deep-tinted
• Fog lamps, front, halogen
• Paint, solid
• Assist Steps, aluminum
• Tires, rear 225/70R19.5G traction blackwall Goodyear Max Axle Load: 15,000 lb.

• Speedometer, miles/kilometers
• Interior trim, Jet Black/Dark Ash (Required and only available with (H2Q/H2R) Dark Ash seats with Jet Black interior accents.)
• Cruise control, steering wheel-mounted
• Door locks, power
• Air conditioning, single-zone
• Assist handle, front passenger and driver on A-pillars
• Floor covering, Graphite-colored rubberized-vinyl
• Steering wheel, urethane
• Upfitter switch kit provides up to 4-30 amp circuits to facilitate installation of aftermarket electrical accessories located on the instrument panel
• Steering column, manual Tilt-Wheel
• Driver Information Center, 3.5-inch diagonal monochromatic display, provides warning messages and basic vehicle information (Included and only available with (IO3) Audio System with 4.2" diagonal color display or (IOR) Chevrolet Infotainment System with 7" diagonal color touch-screen.)
• Mirror, inside rearview manual day/night
• Seat Belt, Black
• Visors, driver and front passenger, vinyl
• Seat trim, Vinyl
• Dark Ash seats with Jet Black interior accents, Vinyl seat trim
• Back-up alarm calibration This calibration will allow installation of an aftermarket back-up alarm by disabling rear perimeter lighting
• Power outlet, 110-volt AC
• Seats, front 40/20/40 split-bench, cloth or vinyl 3-passenger. Includes driver and front passenger recline with outboard head restraints and center fold-down armrest with storage. Also includes manually adjustable driver lumbar and storage pockets. Includes (AG1) 10-way power seat.)
• Remote Keyless Entry
• Seat adjuster, driver 10-way power
• Windows, power with driver express up and down and express down on all other windows

• Exhaust system, right side exit, behind rear wheels (Requires (ED9) 165" wheelbase.)
• Brakes, hydraulic, heavy duty Bosch/Meritor/Wabco system with 4-channel (ABS) (Includes (J69) driveline park brake.)
• Axle, Open rear axle, non-locking rear
• Capped Fuel Fill
• Front axle, 6,250 lb. (2,835 kg), Dana Spicer D800-N, "I"-beam, non-driving (Requires (FTW) 6,250 lb. front suspension. Includes (G68) rear shock absorbers. Not available with rear air suspensions.)
• Steering, power (Bosch S2 8014 Plus)
• Fuel tank, rear only, 40 gallon mounted between frame side rails and behind rear axle
• Emissions, USA 50 State certified
• Front suspension, 6,250 lb. (2,835 kg) multi-leaf, includes shock absorbers (Not available with LiquidSpring prep or rear air suspensions.) (STD)
• Rear wheel drive
• Incomplete vehicle
• Fuel, diesel B20
• Axle lubricant, rear, synthetic oil EmGard FE -75W-90
• Rear axle, 4.10 ratio Max road speed: 79 MPH
• Shock Absorbers, rear (Included with (FTC) 6,250 lb. front axle.)
• Trailering provisions, trailering wire harness only, trailer combined (Stop/Tail/Turn) connection socket and harness mounted at rear of frame.
• Exhaust brake
• Trailer brake controller, integrated
• Wheelbase, 165" (419.1 cm), 84" CA (Requires (F0C) 49" axle to end of frame, (F0D) 63" axle to end of frame or (F0K) 91" axle to end of frame. Requires (PCJ) Vocational Specific Heavy Suspension Package, when ordering (FTA) 7,000 lb. Front axle/(FK6) 7,000 lb. Front suspension or (FTL) 8,000 lb. Front axle/(FSN) 8,000 lb. Front suspension and/or (FU7) 15,500 lb. rear suspension.) (STD)
• Axle to End of Frame, 49" (Requires wheelbase (ED5) 201", (ED9) 165" or (ER2) 189". Not available with (G40), (GP1) or (GP8) rear air suspension.)
• Emissions, 50 state certification
• Front suspension, 6,250 lb. (2,835 kg) multi-leaf, includes shock absorbers (STD)
• Battery, top post threaded, battery jump start stud (located on battery box)
• Axle, limited slip, Dana Spicer Truetrac, torque proportioning limited slip
• Shock Absorbers, rear
• 30,000 lb. GCWR (13,607 kg)
• Tool kit, Rim Wrench and handle only
• Wheelbase, 165" (419.1 cm), 84" CA (STD)
• Rear axle, 15,000 lb. (6,804 kg) Dana Spicer S16-130, single reduction
• 5500 HD Series
• Rear suspension, 13,500 lb. (6,123 kg) multi-leaf, vari-rate
• GVWR, 19,500 lb. (8845 kg)
• Front axle, 6,250 lb. (2,835 kg), Dana Spicer D800-N, "I"-beam, non-driving Includes (G68) rear shock absorbers.
• Alternator, 220 amps
• Recovery hooks, front, frame-mounted, black
• Batteries, heavy-duty dual 1300 cold-cranking amps includes battery box mounted to left side under cab
• Rear axle, 4.10 ratio Max road speed: 79 MPH
• DPF, diesel particulate filter, manual regeneration customer regeneration will not be allowed until the DPF load percentage has reached 100% full and a driver information center (DIC) message has been shown

• Snow Plow Prep Package includes (UNL) auxiliary harness for headlamps and turn signals, (KW5) 220-amp alternator, forward lamp wiring harness and (TRW) provision for cab roof mounted lamp/beacon
• Work Truck Preferred Equipment Group includes standard equipment

• Daytime Running Lamps, with automatic exterior lamp control

• Airbags, Single-stage frontal airbags for driver and front outboard passenger; Seat-mounted side-impact airbags for driver and front outboard passenger; Head-curtain airbags for front outboard seating positions; Includes airbag deactivation switch for front outboard passenger airbag (Always use seat belts and child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owner's Manual for more information.)
• Rear Vision Camera, display integrated into Radio (Shipped loose in cab for upfitter installation.)
• OnStar, delete
• Airbag deactivation switch, frontal passenger-side (Included and only available with (AY0) airbags.)
• Horn, dual-note

• StabiliTrak, Electronic Stability Control System with Traction Control includes Electronic Trailer Sway Control and Hill Start Assist
• Brake, parking, driveline park brake system
• Traction control

Snow Plow Prep Package

• PAINT SCHEME

• STYLE 1

  WINDOWS

• POWER WITH DRIVER EXPRESS UP AND DOWN AND EXPRESS DOWN ON ALL OTHER WINDOWS

  SEAT ADJUSTER

• DRIVER 10-WAY POWER

  GLASS

• DEEP-TINTED

  REMOTE KEYLESS ENTRY

  ASSIST STEPS

• ALUMINUM

  SHOCK ABSORBERS

• REAR

  AXLE

• LIMITED SLIP
• DANA SPICER TRUETRAC
• TORQUE PROPORTIONING LIMITED SLIP

  REAR SUSPENSION

• 13
• 500 LB. (6
• 123 KG) MULTI-LEAF
• VARI-RATE

  STERLING GRAY METALLIC

  GVWR

• 19
• 500 LB. (8845 KG)

  DARK ASH SEATS WITH JET BLACK INTERIOR ACCENTS

• VINYL SEAT TRIM

  REAR AXLE

• 15
• 000 LB. (6
• 804 KG)

  POWER OUTLET

• 110-VOLT AC

  ALTERNATOR

• 220 AMPS

  STEERING WHEEL

• LEATHER-WRAPPED WITH AUDIO AND CRUISE CONTROLS

  30

• 000 LB. GCWR (13
• 607 KG)

  5500 HD SERIES

  FOG LAMPS

• FRONT
• HALOGEN

  SINGLE-SLOT CD/MP3 PLAYER

  HORN

• DUAL-NOTE

  DRIVER INFORMATION CENTER

• 4.2-INCH DIAGONAL COLOR DISPLAY
• INCLUDES DRIVER PERSONALIZATION
• WARNING MESSAGES AND VEHICLE INFORMATION

  STEERING WHEEL AUDIO CONTROLS

  AUXILIARY HARNESS

• 3' FOR HEADLAMPS AND TURN SIGNALS

  6-SPEAKER AUDIO SYSTEM

  TOOL KIT

• RIM WRENCH AND HANDLE ONLY

  RECOVERY HOOKS

• FRONT
• FRAME-MOUNTED
• BLACK

  PAINT

• SOLID

• DriveType
• DriveType: Rear Wheel Drive
• Fuel Economy
• City: 0
• Hwy: 0
• Combined: 0
• Fuel System
• Fuel System: Direct Injection
• Fuel Tank Capacity
• Fuel Tank Capacity: 65 gal
• Fuel Type
• Fuel Type: Diesel Fuel
• Horse Power
• Horse Power: 350
• Rear Wheel
• Rear Wheel: Dual
• Trailering Capacity
• Trailering Capacity: 0
