• Lamps, rear, stop/turn/backup (1-piece assembly) with license plate light
• Grille guard screen, insect protection (mounted behind grille)
• Antenna, fixed mast
• Front fender extension, painted body color
• Lamps, cargo area, cab mounted with switch on center switch bank
• Lamps, Smoked Amber roof marker
• Headlamps, halogen projector-beam
• Assist Steps, aluminum
• Tire valve cap, (Alligaro V2B) flo-thru
• Grille, chrome
• Tires, front 225/70R19.5H traction blackwall Continental Max Axle Load: 8,000 lb.
• Paints, solid, Wheatland Yellow All normally body colored non-sheet metal parts will be Black. May require extended lead time.
• Air Compressor Accessory Drive
• Bumper, front chrome
• Door handles, outside, chrome
• Tires, rear 225/70R19.5H traction blackwall Continental Max Axle Load: 16,000 lb.
• Special Paint, Solid, one color All normally body colored non-sheet metal parts will be Black. May require extended lead time.
• Tire, Spare 225/70R19.5H traction blackwall Continental Includes (V33) Rim Wrench and handle only tool kit.)
• Electrical Provisions, rear of frame, upfitter, body builder wiring includes Sealed Connectors for Tail/Amber Turn/Marker/Backup/Accessory Power/Ground and Sealed Connector for Stop/Turn
• Paint Scheme, Style 1
• Mirrors, outside, black, heated power-adjustable, high-visibility vertical camper-style, and lower convex spotter glass, manual-folding. Convex glass is not heated and not power adjustable. 102", Wide Load
• Wheels, 19.5" x 6.75", 6-aluminum wheels, 8-holes, hub piloted Dura-Bright finish is on the outside of the wheel
• Wheel, 19.5" x 6.75", spare, aluminum, 8-holes temporary mounted on frame. Dura-Bright finish is on the outside of the wheel.
• Glass, deep-tinted

• Visors, driver and front passenger, vinyl
• Seat trim, Vinyl
• Speedometer, miles/kilometers
• Interior trim, Jet Black/Dark Ash (Required and only available with (H2Q/H2R) Dark Ash seats with Jet Black interior accents.)
• Cruise control, steering wheel-mounted
• Door locks, power
• Air conditioning, single-zone
• Assist handle, front passenger and driver on A-pillars
• Floor covering, Graphite-colored rubberized-vinyl
• Steering wheel, urethane
• Upfitter switch kit provides up to 4-30 amp circuits to facilitate installation of aftermarket electrical accessories located on the instrument panel
• Steering column, manual Tilt-Wheel
• Driver Information Center, 3.5-inch diagonal monochromatic display, provides warning messages and basic vehicle information (Included and only available with (IO3) Audio System with 4.2" diagonal color display or (IOR) Chevrolet Infotainment System with 7" diagonal color touch-screen.)
• Mirror, inside rearview manual day/night
• Seat Belt, Black
• Back-up alarm calibration This calibration will allow installation of an aftermarket back-up alarm by disabling rear perimeter lighting
• Key system, 2 spare keys
• Seats, front 40/20/40 split-bench, cloth or vinyl 3-passenger. Includes driver and front passenger recline with outboard head restraints and center fold-down armrest with storage. Also includes manually adjustable driver lumbar and storage pockets. Includes (AG1) 10-way power seat.)
• Remote Keyless Entry
• Provisions for electrical switch bank consists of (6) two position, latching, rocker style switch modules with an on/off indicator window. The application of each switch will be defined by the customer/up fitter. Located on Headliner.
• Jet Black, Cloth seat trim includes manually adjustable driver lumbar
• Seat adjuster, driver 10-way power
• Windows, power with driver express up and down and express down on all other windows

• Emissions, 50 state certification
• Brakes, hydraulic, heavy duty Bosch/Meritor/Wabco system with 4-channel (ABS) (Includes (J69) driveline park brake.)
• Axle, Open rear axle, non-locking rear
• Capped Fuel Fill
• Steering, power (Bosch S2 8014 Plus)
• Emissions, USA 50 State certified
• Rear wheel drive
• Incomplete vehicle
• Fuel, diesel B20
• Axle lubricant, rear, synthetic oil EmGard FE -75W-90
• Shock Absorbers, rear (Included with (FTC) 6,250 lb. front axle.)
• Trailering provisions, trailering wire harness only, trailer combined (Stop/Tail/Turn) connection socket and harness mounted at rear of frame.
• Exhaust brake
• Trailer brake controller, integrated
• Batteries, heavy-duty dual 1300 cold-cranking amps includes battery box mounted to left side under cab
• Front suspension, 8,000 lb. (3,629 kg) multi-leaf, includes shock absorbers
• Rear axle, 15,500 lb. (7,031 kg)
• DPF, diesel particulate filter, manual regeneration customer regeneration will not be allowed until the DPF load percentage has reached 100% full and a driver information center (DIC) message has been shown
• Battery, top post threaded, battery jump start stud (located on battery box)
• GVWR, 23,500 lb. (10,659 kg)
• Axle, limited slip, Dana Spicer Truetrac, torque proportioning limited slip
• Rear axle, 4.56 ratio Max road speed: 70 MPH
• Tool kit, Rim Wrench and handle only
• Fuel tank, front and rear, 65 gallon total
• Axle to End of Frame, 91"
• Rear suspension - Air, 15,500 lb. (7,031 kg), 5.3" ride height with shock absorbers
• Alternators, dual, 150 amps and 220 amps each
• 6500 HD Series
• 35,000 lb. GCWR (15,875 kg)
• Front axle, 8,000 lb., Dana/Spicer D800-N, "I"-beam, non-driving
• Exhaust system, right side exit ahead of rear wheels
• Front stabilizer bar
• Wheelbase, 231" (586.7 cm), 150" CA

• Work Truck Preferred Equipment Group includes standard equipment
• Wrecker/Rollback Vocational Package

• Daytime Running Lamps, with automatic exterior lamp control

• Airbags, Single-stage frontal airbags for driver and front outboard passenger; Seat-mounted side-impact airbags for driver and front outboard passenger; Head-curtain airbags for front outboard seating positions; Includes airbag deactivation switch for front outboard passenger airbag (Always use seat belts and child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owner's Manual for more information.)
• Rear Vision Camera, display integrated into Radio (Shipped loose in cab for upfitter installation.)
• OnStar, delete
• Airbag deactivation switch, frontal passenger-side (Included and only available with (AY0) airbags.)
• Horn, dual-note
• Backup alarm (Includes (SFW) SEO Calibration for backup alarm.

• StabiliTrak, Electronic Stability Control System with Traction Control includes Electronic Trailer Sway Control and Hill Start Assist
• Brake, parking, driveline park brake system
• Traction control

REAR AXLE, 4.56 RATIO

• Max road speed: 70 MPH

WORK TRUCK PREFERRED EQUIPMENT GROUP

• includes standard equipment

ELECTRICAL PROVISIONS, REAR OF FRAME, UPFITTER, BODY BUILDER WIRING

• includes Sealed Connectors for Tail/Amber Turn/Marker/Backup/Accessory Power/Ground and Sealed Connector for Stop/Turn

BATTERIES, HEAVY-DUTY DUAL 1300 COLD-CRANKING AMPS

• includes battery box mounted to left side under cab

PAINTS, SOLID, WHEATLAND YELLOW

• All normally body colored non-sheet metal parts will be Black. May require extended lead time.

SEATS, FRONT 40/20/40 SPLIT-BENCH, CLOTH OR VINYL 3-PASSENGER.

• Includes driver and front passenger recline with outboard head restraints and center fold-down armrest with storage. Also includes manually adjustable driver lumbar and storage pockets. Includes (AG1) 10-way power seat.)

BATTERY, TOP POST THREADED, BATTERY JUMP START STUD

• (located on battery box)

MIRRORS, OUTSIDE, BLACK, HEATED POWER-ADJUSTABLE, HIGH-VISIBILITY VERTICAL CAMPER-STYLE, AND LOWER CONVEX SPOTTER GLASS, MANUAL-FOLDING.

• Convex glass is not heated and not power adjustable. 102"
• Wide Load

DPF, DIESEL PARTICULATE FILTER, MANUAL REGENERATION

• customer regeneration will not be allowed until the DPF load percentage has reached 100% full and a driver information center (DIC) message has been shown

JET BLACK, CLOTH SEAT TRIM

• includes manually adjustable driver lumbar

AUDIO SYSTEM, CHEVROLET INFOTAINMENT SYSTEM WITH 7" DIAGONAL COLOR TOUCH-SCREEN

• AM/FM stereo with seek-and-scan and digital clock
• includes Bluetooth® handsfree calling and streaming audio with select phones; wired phone projection via select 3rd party apps (late feature availability); USB ports; auxiliary jack. (Includes (UQ3) 6-speaker audio system.

ENGINE, DURAMAX 6.6L TURBO-DIESEL V8, B20-DIESEL COMPATIBLE

• 350 hp @ 2500 rpm
• 750 lb.-ft. torque @ 1400 rpm (STD)

RUGGED DUTY SERVICE TRANSMISSION, AUTOMATIC CLOSE-RATIO 6 SPD WITH DOUBLE OVERDRIVE, ALLISON, A2750RDS

• ratios: 3.10 1ST
• 1.80 2ND
• 1.40 3RD
• 1.00 4TH
• 0.70 5TH
• 0.61 6TH Rugged Duty Series
• includes park pawl

POWER TAKE OFF, ENGINE CONTROL PROVISIONS

• Access is available on left-hand and right-hand side

WHEELS, 19.5" X 6.75", 6-ALUMINUM WHEELS, 8-HOLES, HUB PILOTED

• Dura-Bright finish is on the outside of the wheel

WHEEL, 19.5" X 6.75", SPARE, ALUMINUM, 8-HOLES

• temporary mounted on frame. Dura-Bright finish is on the outside of the wheel.

BACK-UP ALARM CALIBRATION

• This calibration will allow installation of an aftermarket back-up alarm by disabling rear perimeter lighting

SPECIAL PAINT, SOLID, ONE COLOR

• All normally body colored non-sheet metal parts will be Black. May require extended lead time.

PROVISIONS FOR ELECTRICAL SWITCH BANK

• consists of (6) two position
• latching
• rocker style switch modules with an on/off indicator window. The application of each switch will be defined by the customer/up fitter. Located on Headliner.

BACKUP ALARM

• (Includes (SFW) SEO Calibration for backup alarm.

TIRES, FRONT 225/70R19.5H TRACTION BLACKWALL CONTINENTAL

• Max Axle Load: 8
• 000 lb.

TIRES, REAR 225/70R19.5H TRACTION BLACKWALL CONTINENTAL

• Max Axle Load: 16
• 000 lb.

TIRE, SPARE 225/70R19.5H TRACTION BLACKWALL CONTINENTAL

• Includes (V33) Rim Wrench and handle only tool kit.)

• PAINT SCHEME

• STYLE 1

  KEY SYSTEM

• 2 SPARE KEYS

  WINDOWS

• POWER WITH DRIVER EXPRESS UP AND DOWN AND EXPRESS DOWN ON ALL OTHER WINDOWS

  SEAT ADJUSTER

• DRIVER 10-WAY POWER

  GLASS

• DEEP-TINTED

  REMOTE KEYLESS ENTRY

  GVWR

• 23
• 500 LB. (10
• 659 KG)

  ASSIST STEPS

• ALUMINUM

  DOOR HANDLES

• OUTSIDE
• CHROME

  AXLE TO END OF FRAME

• 91"

  FRONT STABILIZER BAR

  WHEELBASE

• 231" (586.7 CM)
• 150" CA

  FRONT SUSPENSION

• 8
• 000 LB. (3
• 629 KG) MULTI-LEAF
• INCLUDES SHOCK ABSORBERS

  FRONT AXLE

• 8
• 000 LB.
• DANA/SPICER D800-N
• "I"-BEAM
• NON-DRIVING

  AXLE

• LIMITED SLIP
• DANA SPICER TRUETRAC
• TORQUE PROPORTIONING LIMITED SLIP

  REAR SUSPENSION - AIR

• 15
• 500 LB. (7
• 031 KG)
• 5.3" RIDE HEIGHT WITH SHOCK ABSORBERS

  REAR AXLE

• 15
• 500 LB. (7
• 031 KG)
• DANA SPICER S16-140
• SINGLE REDUCTION

  ALTERNATORS

• DUAL
• 150 AMPS AND 220 AMPS EACH

  AIR COMPRESSOR ACCESSORY DRIVE

  EXHAUST SYSTEM

• RIGHT SIDE EXIT AHEAD OF REAR WHEELS

  FUEL TANK

• FRONT AND REAR
• 65 GALLON TOTAL

  WRECKER/ROLLBACK VOCATIONAL PACKAGE

  TIRE VALVE CAP

• (ALLIGARO V2B) FLO-THRU

  35

• 000 LB. GCWR (15
• 875 KG)

  6500 HD SERIES

  HORN

• DUAL-NOTE

  6-SPEAKER AUDIO SYSTEM

  GRILLE

• CHROME

  TOOL KIT

• RIM WRENCH AND HANDLE ONLY

  BUMPER

• FRONT CHROME

• DriveType
• DriveType: Rear Wheel Drive
• Fuel Economy
• City: 0
• Hwy: 0
• Combined: 0
• Fuel System
• Fuel System: Direct Injection
• Fuel Tank Capacity
• Fuel Tank Capacity: 65 gal
• Fuel Type
• Fuel Type: Diesel Fuel
• Horse Power
• Horse Power: 350
• Rear Wheel
• Rear Wheel: Dual
• Trailering Capacity
• Trailering Capacity: 0
