• Front fender extension, painted body color
• Lamps, cargo area, cab mounted with switch on center switch bank
• Lamps, Smoked Amber roof marker
• Headlamps, halogen projector-beam
• Lamps, rear, stop/turn/backup (1-piece assembly) with license plate light
• Grille guard screen, insect protection (mounted behind grille)
• Antenna, fixed mast
• Mirrors, outside heated power-adjustable vertical trailering, upper glass, manual-folding and extending, black. Includes integrated turn signal indicators consisting of 51 square inch flat mirror surface positioned over a 24.5 square inch convex mirror surface with a common head and lower convex spotter glass (convex glass is not heated and not power adjustable) and addition of Auxiliary cargo lamp for backing up (helps to see trailer when backing up with a trailer) and amber auxiliary clearance lamp
• Tires, rear 225/70R19.5G traction blackwall Pirelli Max Axle Load: 15,000 lb.
• Summit White
• License plate kit, front
• Wheel, 19.5" x 6.75", spare, aluminum, 8-holes temporary mounted on frame. Dura-Bright finish is on the outside of the wheel.
• Glass, deep-tinted
• Fog lamps, front, halogen
• Paint, solid
• Assist Steps, aluminum
• Tire, Spare 225/70R19.5G Traction blackwall Pirelli Includes (V33) Rim Wrench and handle only tool kit.)
• Tires, front 225/70R19.5G traction blackwall Pirelli Max Axle Load: 7,940 lb.
• Mirror caps, chrome
• Grille, chrome
• Bumper, front chrome
• Door handles, outside, chrome
• Provision for cab roof-mounted lamp/beacon provides an overhead console mounted switch and electrical wiring tucked beneath the headliner for a body upfitter to connect a body-mounted warning or emergency lamp
• Wheels, 19.5" x 6.75", 4-aluminum wheels, 8-holes, hub piloted Dura-Bright finish is on the outside of the wheel
• Auxiliary harness, 3' for headlamps and turn signals

• Assist handle, front passenger and driver on A-pillars
• Floor covering, Graphite-colored rubberized-vinyl
• Steering wheel, urethane
• Upfitter switch kit provides up to 4-30 amp circuits to facilitate installation of aftermarket electrical accessories located on the instrument panel
• Steering column, manual Tilt-Wheel
• Driver Information Center, 3.5-inch diagonal monochromatic display, provides warning messages and basic vehicle information (Included and only available with (IO3) Audio System with 4.2" diagonal color display or (IOR) Chevrolet Infotainment System with 7" diagonal color touch-screen.)
• Mirror, inside rearview manual day/night
• Seat Belt, Black
• Visors, driver and front passenger, vinyl
• Seat trim, Vinyl
• Seat, rear 60/40 folding bench (folds up), 3-passenger (includes child seat top tether anchor)
• Windows, power with driver express up and down and express down on all other windows
• Speedometer, miles/kilometers
• Interior trim, Jet Black/Dark Ash (Required and only available with (H2Q/H2R) Dark Ash seats with Jet Black interior accents.)
• Cruise control, steering wheel-mounted
• Door locks, power
• Air conditioning, single-zone
• Wiring harness accessory for 9L7 wiring to junction block Includes connector and blunt cut wires
• Seat adjuster, driver 10-way power
• Defogger, rear-window electric
• Dark Ash seats with Jet Black interior accents, Vinyl seat trim
• Back-up alarm calibration This calibration will allow installation of an aftermarket back-up alarm by disabling rear perimeter lighting
• Key system, 2 spare keys
• Seats, front 40/20/40 split-bench, cloth or vinyl 3-passenger. Includes driver and front passenger recline with outboard head restraints and center fold-down armrest with storage. Also includes manually adjustable driver lumbar and storage pockets. Includes (AG1) 10-way power seat.)
• Remote Keyless Entry

• Emissions, USA 50 State certified
• Axle to End of Frame, 49" (Requires wheelbase (EM1) 199" or (FNV) 175". Not available with (G40), (GP1) or (GP8) rear air suspension.)
• Rear wheel drive
• Incomplete vehicle
• Fuel, diesel B20
• Axle lubricant, rear, synthetic oil EmGard FE -75W-90
• Rear axle, 4.10 ratio Max road speed: 79 MPH
• Trailering provisions, trailering wire harness only, trailer combined (Stop/Tail/Turn) connection socket and harness mounted at rear of frame.
• Exhaust brake
• Trailer brake controller, integrated
• Emissions, 50 state certification
• Brakes, hydraulic, heavy duty Bosch/Meritor/Wabco system with 4-channel (ABS) (Includes (J69) driveline park brake.)
• Axle, Open rear axle, non-locking rear
• Capped Fuel Fill
• Steering, power (Bosch S2 8014 Plus)
• Rear axle, 15,500 lb. (7,031 kg), Dana Spicer S16-140, single reduction
• 5500 HD Series
• GVWR, 19,500 lb. (8845 kg)
• Wheelbase, 199" (505.5 cm), 84" CA
• Front axle, 8,000 lb., Dana/Spicer D800-N, "I"-beam, non-driving
• Alternator, 220 amps
• Recovery hooks, front, frame-mounted, black
• Exhaust system, right side exit ahead of rear wheels
• Front stabilizer bar
• Batteries, heavy-duty dual 1300 cold-cranking amps includes battery box mounted to left side under cab
• Front suspension, 8,000 lb. (3,629 kg) multi-leaf, includes shock absorbers
• Rear axle, 4.10 ratio Max road speed: 79 MPH
• DPF, diesel particulate filter, manual regeneration customer regeneration will not be allowed until the DPF load percentage has reached 100% full and a driver information center (DIC) message has been shown
• Battery, top post threaded, battery jump start stud (located on battery box)
• Axle, limited slip, Dana Spicer Truetrac, torque proportioning limited slip
• Shock Absorbers, rear
• 30,000 lb. GCWR (13,607 kg)
• Tool kit, Rim Wrench and handle only
• Fuel tank, front and rear, 65 gallon total
• Rear suspension, 15,500 lb. (7,031 kg) multi-leaf, vari-rate

• Snow Plow Prep Package includes (UNL) auxiliary harness for headlamps and turn signals, (KW5) 220-amp alternator, forward lamp wiring harness and (TRW) provision for cab roof mounted lamp/beacon
• Work Truck Preferred Equipment Group includes standard equipment

• Daytime Running Lamps, with automatic exterior lamp control

• Rear Vision Camera, display integrated into Radio (Shipped loose in cab for upfitter installation.)
• OnStar, delete
• Airbag deactivation switch, frontal passenger-side (Included and only available with (AY0) airbags.)
• Airbags, Single-stage frontal airbags for driver and front outboard passenger; Seat-mounted side-impact airbags for driver and front outboard passenger; Head-curtain airbags for front and rear outboard seating positions; (Always use seat belts and child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owner's Manual for more information.)
• Horn, dual-note

• StabiliTrak, Electronic Stability Control System with Traction Control includes Electronic Trailer Sway Control and Hill Start Assist
• Brake, parking, driveline park brake system
• Traction control

Snow Plow Prep Package

• KEY SYSTEM

• 2 SPARE KEYS

  SEAT ADJUSTER

• DRIVER 10-WAY POWER

  GLASS

• DEEP-TINTED

  REMOTE KEYLESS ENTRY

  DEFOGGER

• REAR-WINDOW ELECTRIC

  MIRROR CAPS

• CHROME

  ASSIST STEPS

• ALUMINUM

  DOOR HANDLES

• OUTSIDE
• CHROME

  WHEELBASE

• 199" (505.5 CM)
• 84" CA

  FRONT STABILIZER BAR

  FRONT SUSPENSION

• 8
• 000 LB. (3
• 629 KG) MULTI-LEAF
• INCLUDES SHOCK ABSORBERS

  FRONT AXLE

• 8
• 000 LB.
• DANA/SPICER D800-N
• "I"-BEAM
• NON-DRIVING

  REAR SUSPENSION

• 15
• 500 LB. (7
• 031 KG) MULTI-LEAF
• VARI-RATE

  SHOCK ABSORBERS

• REAR

  AXLE

• LIMITED SLIP
• DANA SPICER TRUETRAC
• TORQUE PROPORTIONING LIMITED SLIP

  SUMMIT WHITE

  GVWR

• 19
• 500 LB. (8845 KG)

  DARK ASH SEATS WITH JET BLACK INTERIOR ACCENTS

• VINYL SEAT TRIM

  REAR AXLE

• 15
• 500 LB. (7
• 031 KG)
• DANA SPICER S16-140
• SINGLE REDUCTION

  ALTERNATOR

• 220 AMPS

  STEERING WHEEL

• LEATHER-WRAPPED WITH AUDIO AND CRUISE CONTROLS

  EXHAUST SYSTEM

• RIGHT SIDE EXIT AHEAD OF REAR WHEELS

  FUEL TANK

• FRONT AND REAR
• 65 GALLON TOTAL

  30

• 000 LB. GCWR (13
• 607 KG)

  5500 HD SERIES

  FOG LAMPS

• FRONT
• HALOGEN

  SINGLE-SLOT CD/MP3 PLAYER

  HORN

• DUAL-NOTE

  DRIVER INFORMATION CENTER

• 4.2-INCH DIAGONAL COLOR DISPLAY
• INCLUDES DRIVER PERSONALIZATION
• WARNING MESSAGES AND VEHICLE INFORMATION

  STEERING WHEEL AUDIO CONTROLS

  AUXILIARY HARNESS

• 3' FOR HEADLAMPS AND TURN SIGNALS

  GRILLE

• CHROME

  TOOL KIT

• RIM WRENCH AND HANDLE ONLY

  BUMPER

• FRONT CHROME

  RECOVERY HOOKS

• FRONT
• FRAME-MOUNTED
• BLACK

  LICENSE PLATE KIT

• FRONT

  PAINT

• SOLID

• DriveType
• DriveType: Rear Wheel Drive
• Fuel Economy
• City: 0
• Hwy: 0
• Combined: 0
• Fuel System
• Fuel System: Direct Injection
• Fuel Tank Capacity
• Fuel Tank Capacity: 65 gal
• Fuel Type
• Fuel Type: Diesel Fuel
• Horse Power
• Horse Power: 350
• Rear Wheel
• Rear Wheel: Dual
• Trailering Capacity
• Trailering Capacity: 0
